IP66 · IK08 · RoHS, CE
Window Cover Series · With Baseplate
5 modules
5 modules from the BOWO Electric Electrical Window Cover. Dimensions: 108 × 122 × 32 mm (4.25 × 4.80 × 1.26 in). Protection: IP66. Contact BOWO Electric for project enquiries.
- External size
- 108 × 122 × 32 mm (4.25 × 4.80 × 1.26 in)
- Material
- Transparent polycarbonate
- Protection
- IP66 · IK08
- Variant
- With Baseplate
Product data
Details introduction
Core product information for specification and project review.
Technical specifications
Model number5 modules
Product familyElectrical Window Cover
VariantWith Baseplate
External dimensions108 × 122 × 32 mm (4.25 × 4.80 × 1.26 in)
MaterialTransparent polycarbonate
Ingress protectionIP66
Impact resistanceIK08
CertificationsRoHS, CE
Temperature range-25°C to +80°C
Installation typeWith baseplate
Customization optionsFlame-retardant and UV-resistant materials; custom CNC openings, laser marking, UV color printing, and other project-specific options.
Product FAQ
What are the dimensions of 5 modules?
5 modules has published external dimensions of 108 × 122 × 32 mm (4.25 × 4.80 × 1.26 in).
What ingress protection does 5 modules provide?
The published ingress protection rating for 5 modules is IP66.
Can 5 modules be customized?
Flame-retardant and UV-resistant materials; custom CNC openings, laser marking, UV color printing, and other project-specific options.
Dimensional drawingAll dimensions in millimeters
Customization readyCNC openings, printing and laser marking
Engineering documentationModel-specific files available on request
Production supportSample confirmation before volume production
